概要

JListのセル内に配置したJLabelのテキストを編集可能にするセルエディタを作成します。

サンプルコード

class EditableList<E extends ListItem> extends JList<E> {
  private transient MouseInputAdapter handler;
  protected final Container glassPane = new EditorGlassPane();
  protected final JTextField editor = new JTextField();
  protected final Action startEditing = new AbstractAction() {
    @Override public void actionPerformed(ActionEvent e) {
      getRootPane().setGlassPane(glassPane);
      int idx = getSelectedIndex();
      ListItem item = getSelectedValue();
      Rectangle rect = getCellBounds(idx, idx);
      Point p = SwingUtilities.convertPoint(
          EditableList.this, rect.getLocation(), glassPane);
      rect.setLocation(p);
      int h = editor.getPreferredSize().height;
      rect.y = rect.y + rect.height - h - 1;
      rect.height = h;
      rect.grow(-2, 0);
      editor.setBounds(rect);
      editor.setText(item.title);
      editor.selectAll();
      glassPane.add(editor);
      glassPane.setVisible(true);
      editor.requestFocusInWindow();
    }
  };
  protected final Action cancelEditing = new AbstractAction() {
    @Override public void actionPerformed(ActionEvent e) {
      glassPane.setVisible(false);
    }
  };
  protected final Action renameTitle = new AbstractAction() {
    @Override public void actionPerformed(ActionEvent e) {
      ListModel<E> m = getModel();
      String title = editor.getText().trim();
      if (!title.isEmpty() && m instanceof DefaultListModel<?>) {
        @SuppressWarnings("unchecked")
        DefaultListModel<ListItem> model = (DefaultListModel<ListItem>) getModel();
        int index = getSelectedIndex();
        ListItem item = m.getElementAt(index);
        model.remove(index);
        model.add(index, new ListItem(editor.getText(), item.icon));
        setSelectedIndex(index);
      }
      glassPane.setVisible(false);
    }
  };

  protected EditableList(DefaultListModel<E> model) {
    super(model);
    editor.setBorder(BorderFactory.createLineBorder(Color.BLACK, 1));
    editor.setHorizontalAlignment(SwingConstants.CENTER);
    // editor.setOpaque(false);
    // editor.setLineWrap(true);

    InputMap im = editor.getInputMap(JComponent.WHEN_FOCUSED);
    im.put(KeyStroke.getKeyStroke(KeyEvent.VK_ENTER, 0), "rename-title");
    im.put(KeyStroke.getKeyStroke(KeyEvent.VK_ESCAPE, 0), "cancel-editing");

    ActionMap am = editor.getActionMap();
    am.put("rename-title", renameTitle);
    am.put("cancel-editing", cancelEditing);

    addMouseListener(new MouseAdapter() {
      @Override public void mouseClicked(MouseEvent e) {
        int idx = getSelectedIndex();
        Rectangle rect = getCellBounds(idx, idx);
        if (rect == null) {
          return;
        }
        int h = editor.getPreferredSize().height;
        rect.y = rect.y + rect.height - h;
        rect.height = h;
        boolean isDoubleClick = e.getClickCount() >= 2;
        if (isDoubleClick && rect.contains(e.getPoint())) {
          startEditing.actionPerformed(new ActionEvent(
              e.getComponent(), ActionEvent.ACTION_PERFORMED, ""));
        }
      }
    });
    getInputMap(JComponent.WHEN_FOCUSED).put(
        KeyStroke.getKeyStroke(KeyEvent.VK_ENTER, 0), "start-editing");
    getActionMap().put("start-editing", startEditing);
  }

  @Override public void updateUI() {
    removeMouseListener(handler);
    setSelectionForeground(null);
    setSelectionBackground(null);
    setCellRenderer(null);
    super.updateUI();
    setLayoutOrientation(JList.HORIZONTAL_WRAP);
    getSelectionModel().setSelectionMode(
        ListSelectionModel.MULTIPLE_INTERVAL_SELECTION);
    setVisibleRowCount(0);
    setFixedCellWidth(56);
    setFixedCellHeight(56);
    setBorder(BorderFactory.createEmptyBorder(5, 10, 5, 10));
    setCellRenderer(new ListItemListCellRenderer<>());
    handler = new ClearSelectionListener();
    addMouseListener(handler);
  }

  protected JTextComponent getEditorTextField() {
    return editor;
  }

  private class EditorGlassPane extends JComponent {
    protected EditorGlassPane() {
      super();
      setOpaque(false);
      setFocusTraversalPolicy(new DefaultFocusTraversalPolicy() {
        @Override public boolean accept(Component c) {
          return Objects.equals(c, getEditorTextField());
        }
      });
      addMouseListener(new MouseAdapter() {
        @Override public void mouseClicked(MouseEvent e) {
          if (!getEditorTextField().getBounds().contains(e.getPoint())) {
            renameTitle.actionPerformed(new ActionEvent(
                e.getComponent(), ActionEvent.ACTION_PERFORMED, ""));
          }
        }
      });
    }

    @Override public void setVisible(boolean flag) {
      super.setVisible(flag);
      setFocusTraversalPolicyProvider(flag);
      setFocusCycleRoot(flag);
    }
  }
}

View in GitHub: Java, Kotlin

解説

  • 水平ニュースペーパー・スタイルレイアウトを設定したJListでアイテム(セル)のタイトル文字列を編集可能にする
  • 選択したセルのタイトル文字列領域がダブルクリックされるとGlassPaneを表示
  • JTextFieldに選択したセルのタイトル文字列を設定
  • GlassPaneJTextFieldを配置してその位置とサイズをセルのタイトル文字列領域と同じになるよう変更
  • JList上にセルエディタとしてGlassPaneごと表示
  • JTextFieldからフォーカスが移動したらGlassPaneを非表示に設定し、JTextFieldのテキストを選択したセルのタイトル文字列に設定
